BK20-600DXXH1N4
BK20-600DXXH1N4 series power module power module, 4 model(s).
The BK20-600DXXH1N4 series is a family of power module power modules rated 20w with wide input 200-1200.
- BK20-600D05H1N4: ±5V / ±2000mA output (20wW)
- BK20-600D12H1N4: ±12V / ±833mA output
- BK20-600D15H1N4: ±15V / ±667mA output
- BK20-600D24H1N4: ±24V / ±417mA output
Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| BK20-600D05H1N4 | 20W | 200-1200 | ±5 | ±2000mA | 4000 | 70*48*23.5 | DIP | 2 |
| BK20-600D12H1N4 | 20W | 200-1200 | ±12 | ±833mA | 4000 | 70*48*23.5 | DIP | 2 |
| BK20-600D15H1N4 | 20W | 200-1200 | ±15 | ±667mA | 4000 | 70*48*23.5 | DIP | 2 |
| BK20-600D24H1N4 | 20W | 200-1200 | ±24 | ±417mA | 4000 | 70*48*23.5 | DIP | 2 |
| Total | 4 models in this series | |||||||
