FG03-C4SXXSS(-1)
FG03-C4SXXSS(-1) series AC-DC open frame power module, 6 model(s).
The FG03-C4SXXSS(-1) series is a family of AC-DC open frame power modules rated 2w / 3w with wide input 85-305VAC/120-430VDC.
- FG03-C4S3V3SS(-1): 3.3V / 600mA output (2wW)
- FG03-C4S05SS(-1): 5V / 600mA output (3wW)
- FG03-C4S09SS(-1): 9V / 333mA output
- FG03-C4S12SS(-1): 12V / 250mA output
- FG03-C4S15SS(-1): 15V / 200mA output
- FG03-C4S24SS(-1): 24V / 125mA output
Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| FG03-C4S3V3SS(-1) | 2W | 85-305VAC/120-430VDC | 3.3V | 600mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| FG03-C4S05SS(-1) | 3W | 85-305VAC/120-430VDC | 5V | 600mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| FG03-C4S09SS(-1) | 3W | 85-305VAC/120-430VDC | 9V | 333mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| FG03-C4S12SS(-1) | 3W | 85-305VAC/120-430VDC | 12V | 250mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| FG03-C4S15SS(-1) | 3W | 85-305VAC/120-430VDC | 15V | 200mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| FG03-C4S24SS(-1) | 3W | 85-305VAC/120-430VDC | 24V | 125mA | 4000 | 35.00 x 18.00 x 11.00 mm | open frame | 1 |
| Total | 6 models in this series | |||||||
