DA150-220SXXG9N3
DA150-220SXXG9N3 series AC-DC open frame module, input 80-264vac, 3 model(s), single output.
The DA150-220SXXG9N3 series is a family of 140.4 / 141.6 / 144 AC-DC open frame power modules. Wide input 80-264vac and single output.
- DA150-220S12G9N3: 12V / 11700mA output (140.4W)
- DA150-220S24G9N3: 24V / 5900mA output (141.6W)
- DA150-220S48G9N3: 48V / 3000mA output (144W)
All models feature an open frame package. Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| DA150-220S12G9N3 | 140.4W | 80-264vac | 12V | 11700mA | 3000 | 105*60*31 | open frame | 1 |
| DA150-220S24G9N3 | 141.6W | 80-264vac | 24V | 5900mA | 3000 | 105*60*31 | open frame | 1 |
| DA150-220S48G9N3 | 144W | 80-264vac | 48V | 3000mA | 3000 | 105*60*31 | open frame | 1 |
| Total | 3 models in this series | |||||||
