FA5-220SXXY2N4
FA5-220SXXY2N4 series AC-DC enclosed power module, 5 model(s).
The FA5-220SXXY2N4 series is a family of AC-DC enclosed power modules rated 4.1w / 5w with wide input 85-305VAC/120-430VDC.
- FA5-220S3V3Y2N4: 3.3V / 1250mA output (4.1wW)
- FA5-220S05Y2N4: 5V / 1000mA output (5wW)
- FA5-220S12Y2N4: 12V / 416mA output
- FA5-220S15Y2N4: 15V / 333mA output
- FA5-220S2415Y2N4: 24V / 208mA output
Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| FA5-220S3V3Y2N4 | 4.1W | 85-305VAC/120-430VDC | 3.3V | 1250mA | 4000 | 50.8*25.4*15.6 | DIP | 1 |
| FA5-220S05Y2N4 | 5W | 85-305VAC/120-430VDC | 5V | 1000mA | 4000 | 50.8*25.4*15.6 | DIP | 1 |
| FA5-220S12Y2N4 | 5W | 85-305VAC/120-430VDC | 12V | 416mA | 4000 | 50.8*25.4*15.6 | DIP | 1 |
| FA5-220S15Y2N4 | 5W | 85-305VAC/120-430VDC | 15V | 333mA | 4000 | 50.8*25.4*15.6 | DIP | 1 |
| FA5-220S2415Y2N4 | 5W | 85-305VAC/120-430VDC | 24V | 208mA | 4000 | 50.8*25.4*15.6 | DIP | 1 |
| Total | 5 models in this series | |||||||
