FA5-220DXXC2N4
FA5-220DXXC2N4 series AC-DC enclosed power module, 4 model(s).
The FA5-220DXXC2N4 series is a family of AC-DC enclosed power modules rated 5w with wide input 85-305vac /120-430vdc.
- FA5-220D05C2N4: +-5V / 500*500mA output (5wW)
- FA5-220D12C2N4: +-12V / 208*208mA output
- FA5-220D15C2N4: +-15V / 167*167mA output
- FA5-220D24C2N4: +-24V / 104*104mA output
Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| FA5-220D05C2N4 | 5W | 85-305vac /120-430vdc | +-5 | 500*500mA | 4000 | 48.5*36*20.5 | DIP | 2 |
| FA5-220D12C2N4 | 5W | 85-305vac /120-430vdc | +-12 | 208*208mA | 4000 | 48.5*36*20.5 | DIP | 2 |
| FA5-220D15C2N4 | 5W | 85-305vac /120-430vdc | +-15 | 167*167mA | 4000 | 48.5*36*20.5 | DIP | 2 |
| FA5-220D24C2N4 | 5W | 85-305vac /120-430vdc | +-24 | 104*104mA | 4000 | 48.5*36*20.5 | DIP | 2 |
| Total | 4 models in this series | |||||||
