FN2-XXXXXC4N
FN2-XXXXXC4N series DC-DC SIP power module, 14 model(s).
The FN2-XXXXXC4N series is a family of DC-DC SIP power modules rated 2w with wide input 4.5-5.5.
- FN2-05D05C4N: ±5V / ±200mA output (2wW)
- FN2-05D09C4N: ±9V / ±111mA output
- FN2-05D12C4N: ±12V / ±84mA output
- FN2-05D15C4N: ±15V / ±67mA output
- FN2-12D05C4N: ±5V / ±200mA output
- FN2-12D09C4N: ±9V / ±111mA output
- FN2-12D12C4N: ±12V / ±84mA output
- FN2-12D12V5C4N: ±12.5V / ±80mA output
- FN2-12D15C4N: ±15V / ±67mA output
- FN2-15D15C4N: ±15V / ±67mA output
- FN2-24D05C4N: ±5V / ±200mA output
- FN2-24D09C4N: ±9V / ±111mA output
- FN2-24D12C4N: ±12V / ±84mA output
- FN2-24D15C4N: ±15V / ±67mA output
Datasheet, samples and OEM/ODM support available on request.
| Part Number | Power | Input Voltage | Output Voltage | Output Current | Isolation Voltage | Size | Package | No. of Outputs |
|---|---|---|---|---|---|---|---|---|
| FN2-05D05C4N | 2W | 4.5-5.5 | ±5 | ±200mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-05D09C4N | 2W | 4.5-5.5 | ±9 | ±111mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-05D12C4N | 2W | 4.5-5.5 | ±12 | ±84mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-05D15C4N | 2W | 4.5-5.5 | ±15 | ±67mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-12D05C4N | 2W | 10.8-13.2 | ±5 | ±200mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-12D09C4N | 2W | 10.8-13.2 | ±9 | ±111mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-12D12C4N | 2W | 10.8-13.2 | ±12 | ±84mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-12D12V5C4N | 2W | 10.8-13.2 | ±12.5 | ±80mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-12D15C4N | 2W | 10.8-13.2 | ±15 | ±67mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-15D15C4N | 2W | 13.5-16.5 | ±15 | ±67mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-24D05C4N | 2W | 21.6-26.4 | ±5 | ±200mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-24D09C4N | 2W | 21.6-26.4 | ±9 | ±111mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-24D12C4N | 2W | 21.6-26.4 | ±12 | ±84mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| FN2-24D15C4N | 2W | 21.6-26.4 | ±15 | ±67mA | 4000vdc | 19.5*7*10 | SIP | 2 |
| Total | 14 models in this series | |||||||
